Concrete Beam Designer
A modern web application for concrete beam analysis and design, featuring load analysis, support configurations, and interactive visualizations.
During my early days in structural engineering, I developed a Cantilever Concrete Retaining Wall Designer to assist with the design and analysis of retaining walls using Python. Today, I’m excited to present its modern version as a web application, powered by Streamlit.
Software developed to streamline the design and detailing process of retaining walls. The program allows:
To run the app locally:
Clone this repository:
git clone https://github.com/felipecordero/retaining_wall.git
Navigate to the project directory:
cd retaining_wall
Install the required dependencies:
pip install -r requirements.txt
Launch the Streamlit app:
streamlit run streamlit_app.py
streamlit run streamlit_app.py
If you want to try the Desktop App:
Navigate to the project directory:
cd retaining_wall
In the file requirements, uncomment the line:
# PyQt5==5.15.11
# PyQt5_sip==12.15.0
Install the required dependencies:
pip install -r requirements.txt
Launch the Streamlit app:
python contencion.py
I welcome contributions to enhance the Cantilever Concrete Retaining Wall Designer. To contribute:
This project is licensed under the MIT License. See the LICENSE file for details.
A heartfelt thank you to the open-source community and the developers of Streamlit for providing the tools that made this project possible.
